Glasfaserkabel

A/I-DQ(ZN)H(SR)H

Glasfaserkabel

Loose tube construction, watertight, rodent protection, halogen-free, flame retardant

Suited for indoor and outdoor use - for fixed laying in cable ducts, conduits or direct burial

Non-binding inquiry
Structure, Laying, Imprint
Application
  • FRP-central element
  • jelly-filled loose tubes, SZ-cabling (if necessary with fillers)
  • strength members (aramide yarns)
  • FRNC-inner sheath (1,5 mm) according to IEC 60332-2, black
  • corrugated steel tape, laminated
  • FRNC-outer sheath (1,5 mm) according to IEC 60332-2, UV-resistant, black



Fiber / tube colors

PENGG KABEL standard according to “Color codes – Fiber optic cables” in the document “General information” in the download area.
Upon customer request we can also manufacture according to other color codes (DIN, TIA / EIA-598 (MPO), IEC).



Standard marking

PENGG KABEL – cable type – fiber count/type – ID number – CPR class CE-marking – meter



On request
  • jelly-filled cable core
  • increased tensile strength
  • FRNC-sheath according to IEC 60332-3
  • increased sheath thicknesses
  • other sheath colors
  • colored stripes
  • other marking



This data sheet describes a standard type.
Numerous variants are available on request.

Product Dates
tube diameter
mm
number of tubes max. fibers / tube max. number of fibers tensile strength
approx. N
weight
approx. kg/km
outer diameter
approx. mm
fire load
MJ/m
2,0

2,3
2,3
2,3
2,3
2,3

2,8
2,8
2,8
2,8
2,8

6*

5*
6
8
10
12

5*
6
8
10
12

4

12
12
12
12
12

24
24
24
24
24

24

60
72
96
120
144

120
144
192
240
288

2.000

2.500
3.000
3.500
4.000
4.500

2.500
3.000
3.500
4.000
4.500

200

195
215
245
290
345

285
320
370
440
510

14,0

14,2
15,0
16,2
17,7
19,5

16,3
17,3
19,0
20,7
22,5

3,5

3,5
4
5
6
7

5
6
7
8
9

* at lower number of tubes corresponding blind elements are used

Technical Details
Technical data

according IEC EN 60794-6 – Indoor/outdoor optical fibre cables

tensile strength see above table
compressive strength (crush) 3000 N/10 cm
impact 25 Nm
torsion 5 cycles ±360°
kink, cable The cable do not form a kink when a loop is drawn together to a diameter 12 times the cable outer diameter.
min. bending radius R = 20 x D (cable outer diameter)
temperature range storage and transport: -40°C up to +70°C
installation: -5°C up to +60°C
operation: -30°C up to +70°C
water penetration No water on free end.



Subject to technical alterations.

CPR - Regulations
Application
  • FRP-central element
  • jelly-filled loose tubes, SZ-cabling (if necessary with fillers)
  • strength members (aramide yarns)
  • FRNC-inner sheath (1,5 mm) according to IEC 60332-2, black
  • corrugated steel tape, laminated
  • FRNC-outer sheath (1,5 mm) according to IEC 60332-2, UV-resistant, black



Fiber / tube colors

PENGG KABEL standard according to “Color codes – Fiber optic cables” in the document “General information” in the download area.
Upon customer request we can also manufacture according to other color codes (DIN, TIA / EIA-598 (MPO), IEC).



Standard marking

PENGG KABEL – cable type – fiber count/type – ID number – CPR class CE-marking – meter



On request
  • jelly-filled cable core
  • increased tensile strength
  • FRNC-sheath according to IEC 60332-3
  • increased sheath thicknesses
  • other sheath colors
  • colored stripes
  • other marking



This data sheet describes a standard type.
Numerous variants are available on request.
